参考标准
GJB773A:2000
IEC 1156标准
Q/TST-05-2018
产品特性
1.低温等级:-60、-70℃、-100℃、-190℃
1.额定电压:300V 600V 1000V
2.方形截面:(32AWG-240mm2)
3.电缆芯数:1-48芯
4.导体:镀锡、镀银、镀镍、裸铜、合金
5.弯曲半径6D(特殊要求)
材料特性
TESTECK/Material property table | |||||||
Fluoropolymer | Special thermoplastic material | Elastomeric material | |||||
FEP | PFA | PTFE | ETFE | PI | PEEK | TPEE | |
Long-term operating temperature(20000h) | -100~+200℃ | -190~+250℃ | -190~+260℃ | -100~+135℃ | -190~+220℃ | -60~ +220℃ | -70℃~+115℃ |
Short-term operating temperature(3000h) | 220℃ | 260℃ | 300℃ | 180℃ | 260℃ | 250℃ | 130℃ |
Chemical resistance | ++ | ++ | ++ | ++ | + | + | + |
Halogen free | × | × | × | × | √ | √ | √ |
ROHS compliance | √ | √ | √ | √ | √ | √ | √ |
REACH compliance | √ | √ | √ | √ | √ | √ | √ |
