参考标准
IEC 1156标准
GY/T186-2002年
干扰描述
低频(通常低于0.75MHZ)
静电屏蔽
在高频条件下
产品特点
1.额定电压:300V 600V 1000V
2.方形截面:(32AWG-240mm2)
3.电缆芯数:1-48芯
4.导体:镀锡、镀银、镀镍、裸铜、合金
5.弯曲半径6D(特殊要求)
材料特性
TESTECK/material property table | ||||||||
Fluoropolymer | Halogen Free Inhibited Polyolefin | Special thermoplastic material | Elastomeric material | |||||
FEP | PFA | PTFE | ECA3000 | LSZH | PI | PEEK | Silikon | |
long-term operating temperature(20000h) | -100~+200℃ | -190~+250℃ | -190~+260℃ | -100~+300℃ | -40~+125℃ | -190~+220℃ | -60~ +220℃ | -50℃~+180℃ |
Short-term operating temperature(3000h) | 220℃ | 260℃ | 300℃ | 320℃ | 150℃ | 260℃ | 250℃ | 200℃ |
Chemical resistance | ++ | ++ | ++ | ++ | ++ | + | + | - |
Halogen free | × | × | × | × | √ | √ | √ | √ |
ROHS compliance | √ | √ | √ | √ | √ | √ | √ | √ |
REACH compliance | √ | √ | √ | √ | √ | √ | √ | √ |
